● Performance Features
1. Acoustically matched to Rexolite.
2. Designed for fillet inspection of composite materials; a single scan can cover the entire fillet area.
3. All array elements emit sound beams incident vertically at 90° to the curved fillet surface, with an incidence mode similar to flat surface inspection.
4. Compatible with different wedges, enabling inspection from both the inner and outer sides of fillets.
