● Additional Notes

   1、The default performance type of the probe is Series R.

   2、The delay block of the probe is preset to protrude 4 mm; an embedded delay block is available upon customization.

   3、The probe is equipped with a Type DA housing by default, featuring no water inlet pipe or water guide groove. For scanning applications requiring fixture clamping, the housing can be replaced with Type CDA (fitted with water inlet pipe, water guide groove and clamping holes).

   4、FS stands for focal sound path and FD for focal depth. The conversion formula among FS, FD and β is:Cosβ=FD/（FS+0.5D）, where D denotes the bore diameter.

   5、Groove markings on both sides of the housing indicate the incident point; the arrow on the top marks the acoustic axis direction, and the red circle on the top signifies that the connector on this side is the transmitting terminal (T).

   6、The probe is fitted with a top-mounted Lemo-00 connector as standard; side-mounted connector orientation can be customized.
