Model

Operating

frequency

Effective

firing aperture

Geometric

focal length

Central hole

Theoretical

focal diameter

Theoretical depth

Rated output

sound power

Focal zone

sound intensity

（MHz)

(mm)

(mm)

(mm)

(-6dB,mm)

（-6dB, mm）

（W)

（W/cm2)

TP0.5P64F51

0.5

64

51

3.4

18.5

70

785

TP0.5P64F64

0.5

64

64

-

4.2

29.1

70

498

TP1C10F10

1

10

10

-

2.1

14.6

8

228

TP1P24F24

1

24

24

-

2.1

14.6

40

1139

TP1P64F64

1

64

64

-

2.1

14.6

70

1993

TP1P64F64H20

1

64

64

20

4.1

N.D.

70

530

TP2P24F24

2

24

24

-

1.1

7.3

40

4556

TP8P8F8

8

8

8

-

0.26

1.82

5

9113

TP10P6F6

10

6

6

-

0.21

1.46

5

14239
